Installation contactor 32A 3P 230V AC 3xNO THK3-32 TRACON

Product description

Installation contactor is otherwise known as a mechanical switch, it is designed to create a sense of security for users of the electrical system. It also provides a more efficient and effective operation of the entire connected electrical system. This equipment is mounted on rails - you just need to connect the contactor to the circuit. This helps in its faster installation or removal. The key elements of the internal construction, responsible for the operation of the device, are the working contacts - one or more pairs, the coil and the solenoid.

This product works by transmitting a current or voltage signal. When the appropriate voltage is received, the contacts close spontaneously. They can also work with electrical overloads in the installation. This is a product that helps the operation of many electrical devices, extending their life and minimizing the risk of failure.

Technical data:

• EAN : 4015082772567
• Number of normally open main contacts : 0
• Number of positive main contacts : 3
• Number of normally open auxiliary contacts : 0
• Number of normally closed auxiliary contacts : 1
• Type of control voltage : AC
• Main circuit connection type : Screw connection
• Modular version : No
• Rated operating power at AC-3, 400 V [kW] : 15
• Rated control voltage Us for AC 50 Hz [V] to : 42
• Rated control voltage Us for AC 50 Hz [V] from : 42
• Rated control voltage Us for AC 60 Hz [V] to : 48
• Rated control voltage Us for AC 60 Hz [V] from : 48
• Rated operating current Ie at AC-3, 400 V [A] : 32
