Fuse-link gG 160A NT00-160 TRACON fuse link

Product index: NT00-160
Price (with Tax.)
PLN7.80
0 qty.

Ask about product

* Required fields

14 days to return

Free shipping from 499 PLN

Ask a question +48 536 969 696

Product description

The designers and developers of the innovative TRACON concern have been working for the trust of their customers since 1997. During this time, the brand has earned a reputation as one of the leading manufacturers of, among other things: modern overcurrent and residual current circuit breakers, fuses of all sizes and characteristics, and electrotechnical ceramics. The presented model has been described by specialists with variable gL/gG characteristics. In connection with this designation, the device provides effective full-range protection.

The insert is primarily used to protect various types of wires and cables (gL) and the so-called general purpose equipment (gG). During its use, the electrical parameters of the device are not without significance. This is because the insert works at rated voltage, the value of which is 500 V. In turn, the value of the rated current is equal to 250 A. In addition, this model is equipped with a practical top indicator. The presented insert is available in NH2C size. The insert is part of an innovative and popular brand among customers - the WT-NH series.

Technical data:

  • Current: 160A
  • Voltage: 500V.
  • Rated short-circuit breaking current: 120 kA.
  • Ambient temperature: -5 °C...+55 °C.
  • Altitude: 2000 m.
  • Housing material: soapstone mass
  • Melt conductor material: copper (with silver)
