Overcurrent circuit breaker B 40A 3P CLS6 EATON

Product description

Anovercurrent circuit breaker is a component of an electrical installation whose function is to break the continuity of a circuit when the current exceeds the safe value for that circuit. The circuit breaker is designed to control and protect against the effects of overloads and short circuits of consumer circuits of installations, as well as electrical appliances in households.

Technical data:

• Type: CLS6-B40/3
• Rated voltage: 400V AC
• Rated current: 40 A
• Short-circuit current: 6 kA
• Characteristics: B
• Degree of protection: IP20
• Number of poles: 3P
• Width: 52.5 mm (3 mod.)
• Cross-section of connection wires: 1-25 mm2
• Mounting: TS35 mm rail
• Other: contact position indicator (red/green)
