Network-aggregate selector switch 3P 32A SVK3-32 Tracon

With SVK switches, we can turn off, turn on or switch between circuits with an ohm load (even with a slight overload). Three-position switches have 1, 2, 3 and 4 contacts connected. They allow switching from one circuit to another. The contacts in a staggered arrangement make it easier to connect the wires. Switches can be used for switching control modes (manual, off and automatic mode) or switching measurement circuits (e.g. voltage, frequency measurement).

Technical data:

• Rated operating voltage : 240/400 V AC
• Three-pole : rated voltage 32 A
• Operating current (AC-21): Ie = Ith
• Rated insulation voltage: 690 V~
• Rated shock voltage: 6 kV
• Electrical strength (kj): 10000
• Mechanical strength (kj): 20000
• Resistance to flashover (with stray): 10 kA (max 63 A gG/gL)
• Protection against external agents: IP 40 impact and UV protection
• Mounting: on a 35×7.5 mm rail
• Sealability: Sealable in any mode
• Conductors: 1-16 mm2 (flex), 1-16 mm2 (solid)
• Ambient Temp: -25 ... +55 °C
