BANDIT POWER 500W ART computer power supply unit

Product description

Hermetic power supplies are one of the basic components of LED lighting systems. Thanks to the high degree of protection, they are ideal for outdoor systems that are particularly exposed to changing weather conditions or increased humidity. The power supply is distinguished by high quality workmanship. The housing was manufactured from the best materials available on the market. Thanks to this, it is resistant not only to the already mentioned weather conditions, but also to damage of a mechanical nature, such as scratching, crushing or cracking.

What also distinguishes the power supply is, first of all, its compact size and light weight. Thanks to these parameters, it can be used wherever there is limited space or in hard-to-reach places. The versatility and high level of safety provided by the hermetic LED power supply makes it suitable for desktop computers. In addition, it can also be used for all those electronic devices that have an output voltage rating matching it.

Technical specifications:

• Input voltage 230V / 50Hz
• Current on the line +3.3V 30 A
• Current intensity on the +5V line 32 A
• Current intensity on line +12V1 18 A
• Current intensity on line +12V2 17 A
• Maximum power 500 W
• MPC (P1) 20+4 pin power plug type
• ATX12V power plug (P4+4) Yes
• PCI-E power plug (6+2-pin) 1 pc
• Molex power plug (4-pin) 2 pcs
• Mini-Molex power plug (4-pin) 0 pcs
• SATA power plug 3 pcs
• PFC filter Yes ( passive )
• OVP (overvoltage protection) Yes
• OCP (overcurrent protection) Yes
• OPP (overload protection) Yes
• OTP (overheat protection) Yes
• SCP (short circuit protection) Yes
• Fan size 120 mm
• Product dimensions (L x W x H) 150 x 140 x 85 mm
• CE, RoHS compliance
