Miniature relay 1P 12V DC RM50-3011-85-1012 RELPOL

Product description

Miniature relay has a wide range of applications in the category of electronic fuse. This product is made of the highest quality materials, so it is resistant to any damage, both mechanical and technical. This device can be used in electrical installations such as lighting, small household appliances and twilight tools.

This model of relay mainly consists of only two components. The first is the coil and the next is the contacts. In order for the correct contacts to do their "on-off" work, the coil must first be set. To set the coil is to connect the appropriate line voltage to it. The current flowing through the coil creates a magnetic field to attract the steel valve, which is what opens the contact in question.

Technical data:

• Ean: 5900005256714
• Type of control voltage: DC
• Drive polarity: Unpolarized
• Drive switching mode: Monostable
• Number of switching contacts: 1
• Contact type: Single
• Electrical connection type: PCB terminal
• Degree of protection (IP): IP64
• Width [mm]: 15.4
• Height [mm]: 15.5
• Depth [mm]: 19
• Number of NO contacts: 0
• Rated control voltage Us for DC [V] up to: 12
• Rated control voltage Us for DC [V] from: 12
• Number of normally closed contacts: 0
