Power supply 12V/3A mesh 35W POS-35-12-C POS

Product index: POS-35-12-C
Price (with Tax.)
PLN49.50
2 qty.
Remaining order amount to obtain free shipping PLN0.00
Order within 11 hours 45 min. and we will ship tomorrow

Ask about product

* Required fields

14 days to return

Free shipping from 499 PLN

Ask a question +48 536 969 696

Technical information

Supply voltage
230V
Output voltage
12V
Rated power
36W

Product description

Hermetic power supplies are one of the basic components of LED lighting systems. Thanks to the high degree of protection, they are ideal for outdoor systems that are particularly exposed to changing weather conditions or increased humidity. The power supply is distinguished by high quality workmanship. The housing was manufactured from the best materials available on the market. Thanks to this, it is resistant not only to the already mentioned weather conditions, but also to damage of a mechanical nature, such as scratching, crushing or cracking.

What also distinguishes the power supply is, first of all, its compact size and light weight. Thanks to these parameters, it can be used wherever there is limited space or in hard-to-reach places. The versatility and high level of safety provided by the hermetic LED power supply makes it suitable for LED tapes, panels, or bulbs. In addition, it can also be used for all those electronic devices that have an output voltage rating matching it.

Specifications:

  • Dimensions: 99 x 82 x 30mm
  • Weight: 0.2kg
  • Constant-voltage power supply
  • Universal range of input voltage values
  • Free air flow cooled
  • Compliant with candle-wide lighting safety standards

Output

  • Rated voltage 12V
  • Rated current 3A
  • Current range 0 ÷ 3A
  • Rated power 36W
  • Stabilization of UWY depending on changes of UWE ± 0.5%
  • Stabilization of UWY depending on changes of IWY ± 0.5%
  • Voltage tolerance [3] ± 1%
  • Ripple and noise (max.) [2] 120mVP-P
  • Fixing, rise time [4] 1000ms, 35ms / 230VAC under full load
  • Hold time (typical) 30ms / 230VAC under full load

Input

  • Voltage value range 90 ÷ 264VAC
  • Voltage frequency range 47 ÷ 63Hz
  • Power factor (Typ.) PF > 0.6 / 230VAC under full load
  • Efficiency (typ.) 79%
  • AC current (typical) 0.42A/230VAC
  • Inrush current (max.) 45A / 230VAC(25°C)
  • No-load power (max.) 0.2W
