PCU-510 2P 8A 230V AC, 24V F&F time relay

This product allows building groups of relays consisting of min. 2 pcs, for which it is possible to control centrally on the basis of "Turn on all" and "Turn off all". At the same time, each controller in the group can be controlled independently using the local control input. If too many illuminated buttons are connected, there may be spontaneous switching of lighting or switching of lighting permanently.

The contact current given in the technical data is a maximum value and may be subject to limitations. If the information provided shows that the relay in the device is insufficient, it is recommended to use an external switching element (such as a contactor) suitable for switching high surge currents. The relay does not have a "memory" of the contact position. This means that after switching on the power supply the relay contact will always remain in the off state

Technical data:

• Supply voltage 12 V AC/DC
• Operation mode delayed off, delayed on, cyclic operation
• Executive element relay
• Maximum load current 2 × 8 A
• Contact configuration 2 × NO/NC
• Contact separation YES
• Tripping delay 50 ms
• LED red contact status indication
• Operation time - adjustable 0.1 s ÷ 576 hrs.
• Power supply indication LED green
• Connection screw terminals 2.5 mm²
• Tightening torque 0,4 Nm
• Power consumption 0,8 W
• Operating temperature -25 ÷ 50 °C
• Dimensions1 module (18 mm)
• Mounting on a 35 mm rail
• Degree of protection IP20
